Yamaha PSR-SX900 61-Key Arranger Workstation – Yamaha

THE FLAGSHIP

The top-of-the-line in the PSR-SX Series, the PSR-SX900 delivers the best and most available in its class of Arranger Workstations today.

LIMITLESS CREATIVITY

With a completely redesigned sound system, user interface, new assignable functions, Joystick and Live Controllers, you can completely tailor the functions and sounds of PSR-SX900, making your creativity positively limitless.

BE INSPIRED AS YOU INSPIRE

Perfect for songwriting, the PSR-SX900 is packed with rhythmic patterns (called “Styles”) spanning many genres, making it ideal for creating the accompaniment to your musical ideas and an invaluable inspiration for your next composition or arrangement. Together with a tremendous range of expressive sounds and vocal harmony, the PSR-SX900 is your ultimate and inspirational musical partner.

Specifications

• Color/Finish:

  • Body Color: Black
  • Size/Weight:
    • Dimensions:
      • Width: 1017 mm (40″)
      • Height: 139 mm (5.5″)
      • Depth: 431 mm (17″)
    • Weight: 11.5 kg (25.35 lb)
  • Packing Box:
    • Width: 1,181 mm (46-1/2″)
    • Height: 251 mm (9-7/8″)
    • Depth: 524 mm (20-5/8″)

• Control Interface:

  • Keyboard:
    • Number of Keys: 61
    • Type: Organ (FSB), Initial Touch
    • Touch Response: Normal, Soft 1, Soft 2, Hard 1, Hard 2
  • Other Controllers:
    • Joystick: Yes
    • Control Knobs: 2 (assignable)
    • Pitch Bend: Yes
    • Modulation: Yes
  • Display:
    • Type: TFT Color Wide VGA LCD
    • Size: 800 x 480 dots (7 inch)
    • Touch Screen: Yes
    • Color: Color
    • Language: English, German, French, Spanish, Italian
  • Panel Language: English

• Voices:

  • Tone Generation:
    • Tone Generating Technology: AWM Stereo Sampling
  • Polyphony:
    • Number of Polyphony (Max.): 128
  • Preset:
    • Number of Voices: 1337 Voices + 56 Drum/SFX Kits
  • Featured Voices:
    • 252 S.Art!, 54 Mega Voices, 31 Sweet! Voices, 87 Cool! Voices, 131 Live! Voices, 24 Organ Flutes!
  • Compatibility:
    • XG: Yes (for Song playback)
    • GS: Yes (for Song playback)
    • GM: Yes
    • GM2: Yes
  • Expandability:
    • Expansion Voice: Yes (approx. 1 GB)
  • Editing:
    • Voice Set

• Effects:

  • Types:
    • Reverb: 59 Presets + 30 User
    • Chorus: 106 Presets + 30 User
    • DSP: 322 Presets (with VCM) + 30 User
    • Insertion Effect: 1-8: 322 Presets (with VCM) + 30 User
    • Master Compressor: 5 Presets + 30 User
    • Master EQ: 5 Presets + 30 User
    • Part EQ: 28 Parts
  • Others:
    • Mic/Guitar Effects: Noise Gate, Compressor, 3 Band EQ
    • Arpeggio: Yes
    • Vocal Harmony: Number of Presets: Vocal Harmony: 54, Synth Vocoder: 20

• Accompaniment Styles:

  • Preset:
    • Number of Preset Styles: 525
  • Featured Styles:
    • 463 Pro Styles, 46 Session Styles, 10 DJ Styles, 6 Free Play
  • Fingering: Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard
  • Style Control: INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3
  • Other Features:
    • One Touch Setting (OTS): 4 for each Style
    • Chord Looper: Yes
    • Style Section Reset: Yes

• Expandability:

  • Expansion Style: Yes (Internal Memory)
  • Expansion Audio Style: Yes (Internal Memory)
  • Compatibility: Style File Format, Style File Format GE

• Songs:

  • Preset:
    • Number of Preset Songs: 5 Sample Songs
  • Recording:
    • Number of Songs: Unlimited (depends on the drive capacity)
    • Number of Tracks: 16
    • Data Capacity: Approx. 3 MB/Song
  • Recording Function: Quick Recording, Multi Recording, Step Recording
  • Compatible Data Format:
    • Playback: SMF (Format 0 & 1), XF
    • Recording: SMF (Format 0)

• Multi Pads:

  • Preset:
    • Number of Multi Pad Banks: 329 Banks x 4 Pads

• Audio:

  • Audio Link: Yes

• Functions:

  • Registration:
    • Number of Buttons: 8
  • Control: Registration Sequence, Freeze
  • Playlist: Number of Records: 2500 (max.) Records per Playlist file
  • Lesson/Guide:
    • Lesson/Guide: Follow Lights, Any Key, Karao-Key, Your Tempo
  • Search: Registration Bank
  • Demo/Help: Demonstration: Yes
  • Overall Controls:
    • Metronome: Yes
    • Tempo Range: 5 – 500, Tap Tempo
  • Transpose: -12 – 0 – +12
  • Tuning: 414.8 – 440 – 466.8 Hz
  • Octave Button: Yes
  • Scale Type: 9 types
  • Bluetooth: Yes (Audio)

• Miscellaneous:

  • Direct Access: Yes
  • Text Display Function: Yes
  • Wallpaper Customization: Yes
  • Display Out: Yes (by using a commercially available USB display adaptor)

• Storage and Connectivity:

  • Storage:
    • Internal Memory: Yes (approx. 4 GB)
  • External Drives: USB Flash Memory (via USB to DEVICE)
  • Connectivity:
    • Headphones: Yes
    • FOOT PEDAL: 1 (SUSTAIN), 2 (ARTICULATION), Function Assignable
    • Microphone: Microphone/Guitar x 1
    • MIDI: IN, OUT
    • AUX IN: Stereo mini jack
    • LINE OUT: MAIN OUTPUT (L/L+R, R), SUB (AUX) OUTPUT (1,2 (L/L+R, R))
    • USB TO DEVICE: Yes (x 2)
    • USB TO HOST: Yes

• Amplifiers and Speakers:

  • Amplifiers: (15 W + 10 W) x 2
  • Speakers: 13 cm x 2 + 2.5 cm (dome) x 2

• Power Supply:

  • Power Supply: PA-300C or an equivalent recommended by Yamaha
  • Power Consumption: 24 W
  • Auto Power Off Function: Yes

• Accessories:

  • Included Accessories: Owner’s Manual, Online Member Product Registration, Music Rest, AC Adaptor (may not be included depending on your area; check with your Yamaha dealer).
