Korg SQ-1 Re-Issue Sq Sequencer – Korg

SQ-1 is a bus powered or battery operated compact step sequencer with 2 x 8 steps. A broad selection of connectors allow it to control anything from vintage analog synths, to the latest compact synths, or even your DAW. Switch between a variety of sequencer modes and use the step buttons to create spontaneous live performances.

Specifications

• Sequencer Mode

  • ALTERNATE
  • ORDER
  • PARALLEL TURN
  • PARALLEL ORDER
  • CV/DUTY
  • CV/SLIDE
  • CV/DUTY RANDOM
  • RANDOM

• Step Mode

  • GATE ON/OFF
  • ACTIVE STEP
  • SLIDE
  • STEP JUMP

• Sequence Step Resolution

  • Quarter notes
  • Eighth notes
  • Sixteenth notes

• CV OUT Pitch

  • Linear
  • Minor
  • Major
  • Chromatic

• CV OUT Voltage

  • 1V
  • 2V
  • 5V (Oct)
  • 8V (Hz/V)

• GATE OUT Polarity

  • (positive polarity)
  • (negative polarity)

• SYNC IN/OUT Polarity

  • (rise)
  • (fall)

• Connectors

  • littleBits OUT jack (mini monaural phone jack)
  • OUT (MIDI OUT) jack (mini stereo phone jack)
  • CV – A OUT – GATE jack (mini monaural phone jack, CV OUT: Output Level 1V, 2V, 5V, 8[Hz/V], GATE OUT: output level 10V)
  • CV – BOUT – GATE jack (mini monaural phone jack, CV OUT: Output Level 1V, 2V, 5V, 8[Hz/V], GATE OUT: Output Level 10V)
  • IN – SYNC – OUT jack (mini monaural phone jack, SYNC IN: Max Input Level 20V, SYNC OUT: Output Level 5V)
  • USB jack (type B, USB MIDI)

• Power Supply

  • Two AA batteries (alkaline batteries recommended), or USB power

• Battery Life

  • Approximately 5 hours (when using alkaline batteries)

• Dimension (W x D x H)

  • 193 x 84 x 63 mm/7.60″ x 3.31″ × 2.48″

• Weight

  • 641 g/1.41 lbs.

• Included Items

  • Two AA batteries for checking operation
  • Mini plug – DIN cable

• Options

  • Patch cable MS-CABLE-18
