EVH 5150III® 100W Head, Ivory – EVH

The amp that first lanched the EVH line, the 5150III® 100-Watt Head is ideal for almost any playing style you can think of. From rich clean tones to raw rhythms and soaring high gain leads, it does it all at drummer-beating volume. This is the Holy Grail of Tone that Eddie Van Halen has chased his whole life – a truly clean channel, a super-heavy crunch channel and an off-the-scale overdrive channel you simply won’t believe. Each of the three channels has gain, low, mid, high, volume and presence controls. Under the hood, this amp features eight JJ ECC83S (12AX7) preamp tubes and four JJ 6L6 matched power tubes. Sporting unmistakable EVH style, this head is wrapped in a thick textured black or ivory vinyl with black steel grille and white front control panel.

A four-botton footswitch is included, while a high-quality fitted cover is available as an optional accessory item.

Specifications

General:

• Model Number: 2251000400
• Series: EVH® 5150III® Heads
• Color: Ivory
• Amplifier Type: Tube
• Height: 11″ (27.94 cm)
• Width: 30″ (76.2 cm)
• Depth: 12″ (30.5 cm)
• Weight: 55 lbs. (24.95 kg)

Electronics:

• Controls: Gain, Low, Mid, High, Volume, Channel Select, and Presence for Each Channel; Also Global Resonance
• Channels: Three – (Clean, Crunch, and Lead)
• Voltage: 120V (Also Available in 100V, 110V, 220V, 230V, 240V)
• Wattage: 100 Watts
• Effects Loop: 1/4″ (Send/Return)
• Inputs: One – 1/4″
• Line Out: One – 1/4″
• Speaker Jack: Two – 1/4″ Parallel
• Rectifier: Solid State
• Total Impedance: 4, 8, or 16 ohms
• Power Cable: IEC

Construction:

• Grill Cloth/Material: Perforated Steel Front and Rear Panel
• Amplifier Covering: Ivory Textured Vinyl
• Cabinet Material: White Birch

Tubes:

• Preamp Tubes: 8 x JJ ECC83S (12AX7)
• Power Tubes: 4 x JJ 6L6

Hardware:

• Control Knobs: White Chicken-Head Style Pointer
• Handle: Molded Plastic Strap with Nickel-Plated Caps (1 Top & 2 Sides)
• Control Panel: Gain, Low, Mid, High, Volume, Channel Select, and Presence for Each Channel
• Front Panel: White

Accessories:

• Footswitch: 4-Button Footswitch Included
• Footswitch Connection Type: 7-Pin DIN
• Recommended Cover: Optional P/N 0073406000
• Included Accessories: 5-Foot Speaker Cable
